SCEMa configuration and build¶

In the following we will provide an example on how to configure and build SCEMa on a remote machine.

SCEMa on ARCHER2¶

After being successfully logged into the cluster, first load the following modules:

module swap PrgEnv-cray PrgEnv-gnu
module load cmake cray-python
module load cray-fftw

Then enter the work directory (/work) and download petsc, dealii and lammps code into some folders

wget https://ftp.mcs.anl.gov/pub/petsc/release-snapshots/petsc-3.16.2.tar.gz
wget https://github.com/dealii/dealii/releases/download/v9.0.1/dealii-9.0.1.tar.gz
wget https://download.lammps.org/tars/lammps-17Nov2016.tar.gz

After the codes are cloned, unpack them

tar -xvf petsc-3.16.2.tar.gz
tar -xvf dealii-9.0.1.tar.gz
tar -xvf lammps-17Nov2016.tar.gz

Build petsc¶

From within the petsc directory, run the following configure command

./configure --with-cc=cc --with-cxx=CC --with-fc=ftn

And then build petsc

make PETSC_DIR=/work/yours/petsc-3.16.2 PETSC_ARCH=arch-linux-c-debug all
make PETSC_DIR=/work/yours/petsc-3.16.2 PETSC_ARCH=arch-linux-c-debug check

Build deal.II¶

From within the deal.II directory, run the following configure command

mkdir /work/yours/bin/deal.II
CC=cc CXX=CC FC=ftn cmake -DCMAKE_INSTALL_PREFIX=/work/yours/bin/deal.II -DDEAL_II_WITH_MPI=ON -DDEAL_II_WITH_PETSC=ON -DPETSC_DIR=/work/yours/petsc-3.16.2 -DPETSC_ARCH=arch-linux-c-debug  -DDEAL_II_WITH_LAPACK=OFF ..

And then build deal.II

make install (make -j 4 install)
make test

All can be done using a job script, which might look like the following

#!/bin/bash

#SBATCH --job-name=build
#SBATCH --nodes=1
#SBATCH --tasks-per-node=128
#SBATCH --cpus-per-task=1
#SBATCH --time=5:05:00

#SBATCH --account=yours
#SBATCH --partition=standard
#SBATCH --qos=standard

# modules
module swap PrgEnv-cray PrgEnv-gnu
module load cmake cray-python
module load cray-fftw

echo $SLURM_SUBMIT_DIR

# Download
wget https://ftp.mcs.anl.gov/pub/petsc/release-snapshots/petsc-3.16.2.tar.gz
wget https://github.com/dealii/dealii/releases/download/v9.0.1/dealii-9.0.1.tar.gz
wget https://download.lammps.org/tars/lammps-17Nov2016.tar.gz

# Unpack
tar -xvf petsc-3.16.2.tar.gz
tar -xvf dealii-9.0.1.tar.gz
tar -xvf lammps-17Nov2016.tar.gz

# Build PETSc
cd /work/yours/petsc-3.16.2
./configure --with-cc=cc --with-cxx=CC --with-fc=ftn
make PETSC_DIR=/work/yours/petsc-3.16.2 PETSC_ARCH=arch-linux-c-debug all
make PETSC_DIR=/work/yours/petsc-3.16.2 PETSC_ARCH=arch-linux-c-debug check
cd ..


# Build deal.II
mkdir /work/yours/bin/deal.II
cd /work/yours/dealii-9.0.1/build
CC=cc CXX=CC FC=ftn cmake -DCMAKE_INSTALL_PREFIX=/work/yours/bin/deal.II -DDEAL_II_WITH_MPI=ON -DDEAL_II_WITH_PETSC=ON -DPETSC_DIR=/work/yours/petsc-3.16.2 -DPETSC_ARCH=arch-linux-c-debug  -DDEAL_II_WITH_LAPACK=OFF ..

make install
make test
cd ../..

Build LAMMPS¶

From within the LAMMPS directory, move to the src/ directory

cp MAKE/Makefile.mpi MAKE/MACHINES/Makefile.archer2

Then edit the following in MAKE/MACHINES/Makefile.archer2 (e.g. nano MAKE/MACHINES/Makefile.archer2)

CC =            CC
CCFLAGS =       -O3 -Wrestrict
LINK =.         CC
LINKFLAGS =.    -O
LIB =           -lstdc++
LMP_INC =       -DLAMMPS_GZIP
MPI_INC =       -DMPICH_SKIP_MPICXX
FFT_INC=        -DFFT_FFTW3
FFT_LIB=        -lfftw3

And then build LAMMPS

make yes-RIGID
make yes-USER-REAXC
make yes-asphere yes-body yes-class2
make yes-colloid yes-compress
make yes-coreshell yes-dipole yes-granular
make yes-kspace yes-manybody yes-mc
make yes-misc yes-molecule yes-opt
make yes-peri yes-qeq yes-replica
make yes-rigid yes-shock yes-snap
make yes-srd

make -j 8 archer2
make mode=print serial
make mode=shlib archer2

This will create the lmp_archer2 executable. For more detailed approach please visit:

https://github.com/hpc-uk/build-instructions/blob/main/apps/LAMMPS/build_lammps_15Oct2020_gcc930.md

Build SCEMa¶

Within the work directory (/work) clone SCEMa

git clone https://github.com/UCL-CCS/SCEMa.git

From within the SCEMa directory, run the following commands

mkdir build
cp CMakeLists/example_machine.CMakeLists.txt CMakeLists.txt

Where the file CMakeLists.txt needs to be edited to point toward the right installation path, which might look like the following

CMAKE_MINIMUM_REQUIRED(VERSION 3.21)

set(CMAKE_C_COMPILER "cc")
set(CMAKE_CXX_COMPILER "CC")

PROJECT(dealammps LANGUAGES CXX)

FIND_PACKAGE(deal.II 9.0.1 REQUIRED
HINTS /work/yours/bin/deal.II
    )
DEAL_II_INITIALIZE_CACHED_VARIABLES()

ADD_EXECUTABLE(dealammps dealammps.cc)
DEAL_II_SETUP_TARGET(dealammps)

INCLUDE_DIRECTORIES(
/work/yours/lammps-17Nov16/src
/opt/cray/pe/python/default/include/python3.8
)

TARGET_LINK_LIBRARIES(dealammps /work/yours/lammps-17Nov16/src/liblammps.so)
TARGET_LINK_LIBRARIES(dealammps /opt/cray/pe/python/default/lib/libpython3.8.so)

TARGET_LINK_LIBRARIES(dealammps LINK_PUBLIC ${Boost_LIBRARIES})

Then run the following commands

(/work/yours/bin/deal.II must exist!)
cd build
cmake -DDEAL_II_DIR=/work/yours/bin/deal.II ../

Finally build SCEMa

make dealammps

This will create the dealammps executable. For more detailed approach please visit:

https://github.com/UCL-CCS/SCEMa

FabSCEMa Installation¶

Before being able to run FabSCEMa [with the assumption that you have been able to run the basic FabSim examples described in the other documentation files, and that you have configured and built SCEMa (https://github.com/UCL-CCS/SCEMa) on the target machine, and successfully tested the executable code!], you should install FabSCEMa inside of FabSim3. This will provide functionality to extend FabSim3’s workflow and remote submission capabilities to SCEMa specific tasks.

To install FabSim3 tool, please follow the installation from https://fabsim3.readthedocs.io/en/latest/installation.html

To install FabSCEMa plugin, simply type:

fabsim localhost install_plugin:FabSCEMa

After installation of FabSCEMa the following need to be done.

Custom Environments¶

Regardless of the existing python environment on the HPC/local system, you need to setup a custom Python environment including packages that are not in the central installation, the simplest approach here would be the installation of Miniconda locally in your own directories.

Installing Miniconda¶

First, you should download Miniconda (links to the various miniconda versions on the Miniconda website: https://docs.conda.io/en/latest/miniconda.html)

Note

If you wish to use Python on the Archer2’s compute nodes then you must install Miniconda in your /work directories as these are the only ones visible on the compute nodes.

Once you have downloaded the installer, you can run it. For example:

user@login*:~> bash Miniconda3-latest-Linux-x86_64.sh

After you have installed Miniconda and setup your environment to access it, you can install whatever packages you wish using the conda install … command. For example:

(base)user@login*:~> conda install somepy

Installing EasyVVUQ¶

Next you need to install EasyVVUQ in your Miniconda environment to access it. You can install EasyVVUQ using:

(base)user@login*:~> pip install easyvvuq

and upgrade the library using:

(base)user@login*:~> pip install easyvvuq --upgrade

Where (base) can be replaced with your new conda environment

For more detailed approach please visit:

https://github.com/UCL-CCS/EasyVVUQ

Installing EasySurrogate¶

Next you need to install EasySurrogate in your Miniconda environment to access it. You can install EasyVVUQ using:

(base)user@login*:~> pip install easysurrogate

Where (base) can be replaced with your new conda environment

For more detailed approach please visit:

https://github.com/wedeling/EasySurrogate

Installing FabSim3¶

Next you need to install FabSim3 somewhere in your directories and your Miniconda environment to access it.

First you need to check if the following Python modules are already installed

fabric3==1.13.1.post1
PyYAML
numpy
ruamel.yaml
rich

Then install both ruamel.yaml and rich package

pip3 install ruamel.yaml rich

Once you have installed the required packages, then clone FabSim3 from the GitHub repository:

git clone https://github.com/djgroen/FabSim3.git

Finally change to your FabSim3 directory, and type

(base)user@login*:~>python3 configure_fabsim.py

Where (base) can be replaced with your new conda environment

For more detailed approach please visit:

https://github.com/djgroen/FabSim3

Installing QCG-PilotJob¶

Next you need to install QCG-PilotJob somewhere in your Miniconda environment to access it.

You can install QCG-PilotJob using:

(base)user@login*:~> pip install qcg-pilotjob

and supplementary packages can be installed using:

(base)user@login*:~> pip install qcg-pilotjob-cmds
(base)user@login*:~> pip install qcg-pilotjob-executor-api

Where (base) can be replaced with your new conda environment

For more detailed approach please visit:

https://github.com/vecma-project/QCG-PilotJob

Creating virtual environment¶

Finally you need to create a new virtual environment, and update the following files:

easyvvuq_SCEMa_RUN_remote.py
easyvvuq_SCEMa_RUN_localhost.py
SCEMa_easyvvuq_init_run_analyse_local.py
SCEMa_easyvvuq_init_run_analyse_remote.py
SCEMa_init_run_analyse_campaign_local
SCEMa_init_run_analyse_campaign_remote

which are found in

plugins/FabSCEMa/config_files/fabSCEMa_easyvvuq_InRuAn*_QCGPJ plugins/FabSCEMa/config_files/fabSCEMa_easyvvuq_easysurrogate_InRuAn*_DAS_QCGPJ plugins/FabSCEMa/config_files/fabSCEMa_easyvvuq_easysurrogate_InRuAn_GP_QCGPJ plugins/FabSCEMa/config_files/fabSCEMa_easyvvuq_easysurrogate_InRuAn_QSN_QCGPJ plugins/FabSCEMa/templates

This environment is used by EasyVVUQ campaign. For example if you want to execute the SCEMa jobs on a remote machine do only the following:

First, open the file “SCEMa_easyvvuq_init_run_analyse_remote.py” and modify it with your path (your virtual environment)

...
with QCGPJPool(template_params={'venv': '/mnt/lustre/a2fswork2/work/e723/e723/kevinb/venv_kevin'}) as qcgpj:
campaign.execute(pool=qcgpj).collate(progress_bar=True)
...

and then open “FabSCEMa/templates/SCEMa_init_run_analyse_campaign_remote” and modify it with your path (your python environment)

...
/mnt/lustre/a2fs-work2/work/e723/e723/kevinb/miniconda3/envs/py38/bin/python3.8  SCEMa_easyvvuq_init_run_analyse_remote.py  $machine_name    '$run_command_SCEMa'   $SCEMa_exec
...

Note

If you want to run FabSCEMa on your local machine and execute the SCEMa jobs on a remote machine (e.g. fabsim archer2 …), you need to have the virtual environment on remote machine and you only need to have FabSCEMa installed on your local machine (no need for the additional installation of FabSCEMa on a remote machine!)

You can install virtualenv using:

curl https://bootstrap.pypa.io/get-pip.py -o get-pip.py
python3 get-pip.py --user
pip install --user virtualenv

Then to create private virtual environment type:

virtualenv venv
. venv/bin/activate

Once you have installed the required packages and created virtual environment, then install QCG-PilotJob using:

pip install qcg-pilotjob

and supplementary packages can be installed using:

pip install qcg-pilotjob-cmds
pip install qcg-pilotjob-executor-api

For more detailed approach please visit:

https://qcg-pilotjob.readthedocs.io/en/develop/installation.html
